The Hunter Node Controller is a cutting-edge, battery-operated irrigation solution designed for efficient water management. It offers flexible programming, manual operation, and compatibility with DC solenoids, ensuring reliable and efficient performance in any environment.

Overview of the Hunter Node Controller

The Hunter Node Controller is a battery-operated irrigation control solution designed for simplicity and reliability. It mounts directly to solenoids without additional wiring, making installation quick and effortless. The controller is fully waterproof, ensuring durability in harsh outdoor conditions.

Featuring a user-friendly LCD display, the Node Controller allows for easy programming of irrigation schedules. It operates on one or two 9-volt alkaline batteries, providing extended battery life. This innovative system is ideal for remote or power-restricted areas, offering a smart and efficient watering solution.

Key Features and Benefits

The Hunter Node Controller offers a range of innovative features, including a large LCD display with intuitive icons for easy programming. Its battery-operated design eliminates the need for wiring, while the waterproof exterior ensures durability in outdoor environments. With options for single or multi-station control, the Node provides flexibility for various irrigation needs. The ability to manually activate stations or programs enhances user convenience. Additionally, compatibility with DC latching solenoids and sensors ensures seamless integration with existing systems, making it a reliable choice for efficient water management.

Components and Accessories

The Hunter Node Controller includes a solenoid, battery compartment, and LCD display. Multi-station models support up to 6 solenoids, while the SC Probe enhances soil moisture monitoring.

Node Controller Components

The Hunter Node Controller features a user-friendly interface with an LCD display for easy programming and monitoring. It includes a battery compartment for 9-volt alkaline batteries, ensuring reliable operation. The controller is equipped with a mounting clip for secure attachment to valves. Multi-station models support 2, 4, or 6 solenoids, while single-station models come with a pre-attached solenoid. The optional SC Probe integrates soil moisture sensing for optimized watering. Waterproof connectors and a durable design ensure longevity in harsh environments.

Compatible Solenoids and Sensors

The Hunter Node Controller is designed to work exclusively with DC latching solenoids, such as the Hunter P/N 458200, ensuring reliable operation. It supports the SC Probe for soil moisture sensing, enhancing water efficiency. The controller is also compatible with weather sensors, allowing automatic adjustments based on environmental conditions. For proper function, ensure all connections use waterproof connectors and avoid using non-compatible solenoids. The NODE series does not support Hunter Wireless Rain-Clik sensors, but it seamlessly integrates with other Hunter accessories for optimal performance.

Installation Procedures

The Hunter Node Controller installs quickly using a valve mounting clip, eliminating the need for screws or drills. It operates with one or two 9V alkaline batteries and features waterproof connectors for reliable performance.

Mounting the Node to a Valve

To mount the Hunter Node to a valve, first, ensure the water supply is turned off. Attach the valve mounting clip to the solenoid, aligning it securely. Slide the Node onto the clip, ensuring it snaps into place firmly. Connect the solenoid wires to the Node’s terminals, using waterproof connectors to protect against moisture. Finally, test the installation by activating the Node to confirm proper operation;

Connecting Solenoids and Wires

To connect solenoids and wires to the Hunter Node Controller, start by attaching one red wire from each solenoid to the corresponding station wire on the Node; Ensure all connections are secure and protected using waterproof connectors to prevent moisture damage. The Node operates with DC latching solenoids, such as the Hunter DC solenoid (P/N 458200), ensuring compatibility and proper function. After connecting, test the system to confirm all stations activate correctly, ensuring reliable irrigation control.

Installing the SC Probe (If Applicable)

The SC Probe, if applicable, connects to the Hunter Node Controller to monitor soil conditions and optimize watering. To install, locate a suitable spot for the probe, ensuring it accurately reflects soil moisture. Cut the yellow wire loop on the Node and connect the sensor wires. Note that the Node is not compatible with the Hunter Wireless Rain-Clik. Secure the wires to prevent damage and ensure proper system function. After installation, test the probe to confirm it operates correctly with the controller.

Programming the Controller

The Hunter Node Controller offers straightforward programming with push-button controls. Set watering times, days, and advanced features like seasonal adjustments and memory save for customized irrigation management.

Setting the Date and Time

To set the date and time on the Hunter Node Controller, navigate to the programming menu. Use the buttons to adjust the date and time displays. The controller enters idle mode after inactivity to conserve battery power. Press any button to wake the display and access the settings. Accurate time and date are crucial for scheduled watering programs, ensuring your irrigation system operates efficiently and according to your preferences.

Setting Watering Start Times

To set watering start times, press the button to navigate to the programming menu. Use the buttons to adjust the hour and minute displays. The left two digits represent the hour, while the right two show the minutes. Once set, press the button to save and proceed to the next function. Ensure the times align with your desired irrigation schedule for optimal water distribution. This feature ensures your system operates efficiently, adhering to your programmed preferences.

Setting Watering Days

The Hunter Node Controller allows you to customize watering days to suit your needs. Press the button to cycle through options like ODD, EVEN, or specific days of the week. Use the arrows on the display to select the desired days. Once set, the controller will automatically water on those days. After the designated period, it resumes normal operation, ensuring efficient irrigation management without constant adjustments. This feature simplifies scheduling and adapts to varying lawn care requirements.

Advanced Programming Features

The Hunter Node Controller offers advanced programming features, including a memory mode to save preferred programs. This allows users to restore settings easily, ensuring consistency. Seasonal adjustments enable modifying run times by percentages, adapting to weather changes. The controller also features a quick retrieval option for saved programs, enhancing flexibility. These advanced options provide precise control over irrigation schedules, catering to diverse lawn care needs and optimizing water usage efficiently.

Manual Operation

Manual Operation allows activating single stations or entire programs, enabling temporary overrides without changing automatic settings. Users can set specific run times for precise control.

Activating Single Stations

Activating single stations allows precise control over irrigation zones; Users can manually turn on any specific station for a customizable run time, ranging from 1 second to 12 hours. This feature is ideal for addressing specific watering needs without altering programmed schedules. The weather sensor condition, if enabled, is temporarily disregarded during manual single-station mode. The controller’s interface simplifies the process, ensuring quick and efficient operation for targeted water application.

Activating Entire Programs

Activating entire programs allows users to run pre-configured irrigation schedules manually. Programs A, B, or C, with their set run times and stations, can be initiated instantly. This feature is ideal for immediate irrigation needs without altering automatic settings. The weather sensor condition, if active, is temporarily bypassed during manual program activation, ensuring uninterrupted watering. This functionality offers flexibility and control, making it easy to manage irrigation on demand while maintaining the convenience of programmed schedules.

Manual Watering Time Settings

Manual Watering Time Settings allow users to activate a single station for a specified duration, ranging from 1 second to 12 hours. This feature bypasses weather sensor conditions, ensuring watering occurs regardless of external factors. Users can select the desired station, set the run time, and confirm activation. The controller will override automatic schedules temporarily, providing immediate control for specific irrigation needs. This flexibility is ideal for addressing urgent watering requirements without altering programmed settings.

Troubleshooting

Troubleshooting the Hunter Node Controller involves identifying common issues like faulty solenoids or incompatible solenoids. Solutions include replacing solenoids or verifying controller settings to ensure proper operation.

Common Issues and Solutions

Common issues with the Hunter Node Controller include faulty solenoids, incompatible solenoids, or low battery power. Solutions involve replacing faulty solenoids with Hunter DC latching solenoids (P/N 458200) and ensuring proper battery installation. If the controller fails to turn off, verify the system settings or reset the device. For manual operation issues, ensure the weather sensor is bypassed. Always refer to the troubleshooting guide for detailed diagnostic steps and solutions to maintain optimal performance and resolve operational hiccups effectively.

Using the Hunter Quick Check Diagnostic Tool

The Hunter Quick Check Tool is a built-in diagnostic feature that helps identify issues like faulty solenoids or wiring shortcuts. To activate it, press and hold specific buttons from the Idle Mode. This tool quickly detects common faults, such as short circuits caused by bare wires or malfunctioning solenoids. It ensures efficient troubleshooting, allowing users to pinpoint problems without extensive technical knowledge. Regular use of this tool helps maintain system reliability and performance, ensuring your irrigation setup operates smoothly and efficiently at all times.

Specifications

The Hunter Node Controller operates on 1 or 2 9V alkaline batteries, supports DC latching solenoids, and features a water-resistant design with an operating range of -17°C to 60°C.

Technical Details and Compatibility

The Hunter Node Controller is designed for compatibility with DC latching solenoids (P/N 458200) and operates on 9-11VDC. It supports 1 or 2 9V alkaline batteries for extended life. The controller features a robust, waterproof design with an operating temperature range of -17°C to 60°C. It is compatible with Hunter Plastic Valves and works seamlessly with optional sensors like the SC Probe. Dimensions are 3 inches (89 mm) in diameter and 2 inches (64 mm) in height, ensuring a compact and durable construction.

Battery and Power Requirements

The Hunter Node Controller operates on one or two 9-volt alkaline batteries, ensuring extended battery life. Using two batteries prolongs runtime, while a single battery provides sufficient power for standard operation. The controller features a low battery indicator, alerting users when replacement is needed.

It is optimized for use with DC latching solenoids, operating within a 9-11VDC range. No external power source is required, making it ideal for remote or power-restricted locations. Battery replacement is simple, with a secure compartment to prevent water ingress and ensure reliable performance.

Safety and Warranty

The Hunter Node Controller complies with safety standards, ensuring reliable operation. It is backed by a one-year warranty covering defects in materials and workmanship, providing user assurance and protection.

Safety Precautions

Always follow proper safety guidelines when handling the Hunter Node Controller. Ensure the controller is powered off before replacing batteries or performing maintenance. Avoid exposing the device to excessive moisture or submerging it in water. Use only DC latching solenoids compatible with the Hunter Node to prevent damage. Keep the unit out of reach of children and pets. When installing or troubleshooting, ensure all wires are securely connected to avoid short circuits. Regularly inspect the battery compartment for signs of wear or corrosion to maintain optimal performance and safety.

Warranty Information

Hunter Industries provides a comprehensive warranty for the Node Controller, covering defects in materials and workmanship. The warranty period typically ranges from 2 to 5 years, ensuring protection against manufacturing defects. For precise details, including terms and conditions, refer to the official Hunter Industries website or the product’s manual available at www.hunterindustries.com.

The Hunter Node Controller is a reliable and efficient irrigation solution, offering advanced features for smart water management. With its user-friendly interface, long battery life, and durable design, it ensures optimal performance in various environments. Whether for residential or commercial use, the Node Controller provides exceptional value and satisfaction, making it a top choice for modern irrigation needs.
